Alarms
312359J 55
V1M Voltage low control. Always Voltage dropping below 9 Vdc
from power supply.
Change air filter in control filter
regulator. See manual 313289.
Check the pressure setting is
18 psi (0.13 MPa, 1.3 bar) on
turbine air regulator.
Check voltage on information
screen.
Turbine not spinning with air on. Replace air turbine cartridge.
See manual 313289.
N6C Display has no signal. Always No display communication sig-
nal.
Check cable connections.
Replace display.
See manual 313289.
Machine powered down in
spray mode.
Press stop button before turning
off power.
DLA A air motor reed switch signal
missing advisory.
Always Reed switch does not see the
air motor magnet.
Replace air motor reed switch
magnet.
Reed switches are bad. Replace air motor reed switch.
Prevent air motor icing. See
advisory P9A and P9B.
Air motor is icing up.
DLB B air motor reed switch signal
missing advisory.
Always Reed switch does not see the
air motor magnet.
Replace air motor reed switch
magnet.
Reed switches are bad. Replace air motor reed switch.
Prevent air motor icing. See
advisory P9A and P9B.
Air motor is icing up.
DMA A air motor linear sensor
jump advisory.
Always System ran out of fluid. Add fluid to the system.
Linear sensor is bad. Replace linear sensor.
DMB B air motor linear sensor
jump advisory.
Always System ran out of fluid. Add fluid to the system.
Linear sensor is bad. Replace linear sensor.
Optional User-Settable Maintenance Warnings
*MAA
*MAB
Maintain pump. Always, if enabled Pump usage exceeds user-set
limit. Maintenance due.
Service pump. See manual
313289.
*MEA
*MEB
Maintain dosing valve. Always, if enabled Dosing valve usage exceeds
user-set limit. Maintenance
due.
Service dosing valve. See man-
ual 313289.
*MG0 Maintain air filter. Always, if enabled Air filter exceeds user-set limit.
Maintenance due.
Service main air filter and con-
trol filter regulator.See manual
313289.
*P5A
*P5B
Pressure exceeded alarm
limits.
Spray Pressure exceeded high or low
alarm limits for more than 15
seconds.
Adjust pump pressure regulator,
change tips, or adjust target set
point.
Alarm
