Graco XM Series Operation Manual

Alarms
56 312359J
Optional User-Settable Spray Limits
*T5A
T5B
Temperature exceeded alarm
limits.
Spray Fluid temperature exceeded
high or low alarm limits for more
than four minutes.
If fluid temperature is too low,
return to circulation mode to
increase fluid temperature.
Adjust heater set point if
needed. See Heat Fluid, page
31.
If fluid temperature is too high,
lower heater set point, and
return circulation mode to cool.
See Heat Fluid, page 31.
Adjust temperature target set-
point. See Heat Fluid, page 31.
*P2A
P2B
Pressure exceeded advisory
limits.
Spray Pressure exceeded high or low
advisory limits for more than 15
seconds.
Same as P5A or P5B above.
*T2A
T2B
Temperature exceeded advi-
sory limits.
Spray Fluid temperature exceeded
high or low limits for more than
four minutes.
Same as T5A or T5B above.
*N4D Pot life timer expired. Mixed
fluid will cure in hoses, mixer,
and gun.
Spray Have not sprayed enough vol-
ume to keep fresh mixed fluid in
the integration hose, mixer,
whip hose, and spray gun.
Spray fluid, or flush. Resets
when you leave spray mode.
See Spray, page 32, or Flush
Mixed Material, page 36.
Alarm
Code Alarm Problem When Active Cause Solution
