Parts
72 3A0420ZAF
Mounted Heated Hose Parts List
Ref. Part Description Qty. (273095) Qty. (273094) Qty. (273102)
401 245869 HEATER, paint, non-hazardous locations
1
245863 HEATER, paint, hazardous locations
1
245870 HEATER, paint, non-hazardous locations
1
402 24N445 BRACKET, heater, heated hose, paint
111
403 126898 FITTING, elbow, 1/2 tube x 1/2 NPTM
111
404 126896 FITTING, elbow, 1/2 tube x 1/2 NPTF
111
405 17P759 TUBE, 48 in. x 0.5 OD, nylon
111
406 126900 FITTING, 1/2 tube x 3/8 NPTM
111
407 17D306 FITTING, coupler, quick coupling
111
408 17N600 HARNESS, sw5 to hose heat
1
1
409 116171 BUSHING, strain relief
1
1
410 122032 NUT, wire
2
2
411 166590 FITTING, elbow, street
1
413 123443 SCREW, cap, flng hd
444
414 24N447 BRACKET, base, heated hose, painted
111
415 113981 NUT, lock, high tensile
444
416 185065 ADAPTER, cable
1
Replacement Danger and Warning labels, tags, and cards are available at no cost.
