Dimensions
3A0420ZAF 85
Dimensions
WLD
WLD
WLD
32 in.
(81.3 cm)
52 in.
(13.2 cm)
62 in.
(157.4 cm)
35 in.
(88.9 cm)
Full System
Bare System
Top View
Side View
XP System
XP-h System
63 in.
(160 cm)
