Graco XP-H Series User Manual

Parts
3A0420ZAF 79
XPh Pump Package
 Replacement safety labels, tags, and cards are available
at no cost.
Ref. Part Description Qty.
801 262465 PLATE, motor 1
802 16M882 ROD, tie, 5.0 in. long 3
803 262818 MOTOR, hydraulic 1
804 16M654 ROD, adapter 1
805 262468 ROD, tie, 14.25 in. long w/
shoulder
4
806 262469 ROD, tie, 14.25 in. long, 1.25 in.
dia.
2
807 154636 WASHER, flat 3
808 101712 NUT, lock, 5/8 - 11 9
809 16D451 NUT, yoke 1
810 262470 BRACKET, ratio indicator 1
811 262471 YOKE, pump assembly 1
812 15H392 ROD, adapter, Xtreme 2
813 262472 SLEEVE, with bearing 2
816 123976 RING, snap, external 2
821 262814 KIT, cover, air motor 1
822 262474 KIT, cover, pump 2
822a 121803 SCREW, button head, #10-32 x
0.5 in.
4
822b 124172 WASHER, nylon, #10-32 4
822c 124665 NUT, captive, #10-32 2
822d 15T468 LABEL, warning 1
830 124078 CLAMP, spring 2
831 15H108 LABEL, safety warning 2
834 262475 PLATE, ratio indicator 1
835 16E882 STRAP, lowers 2
840 244524 WIRE, ground 1
841 16N396 LABEL, XPh 1
842 16N375 LABEL, warning 1
893 196142 FITTING, adapter 1
894 17E119 COUPLER, hydraulic 1
895 158555 FITTING, nipple, adapter 1
896 17E121 COUPLER, hydraulic 1
898 206995 FLUID, TSL 1
899 16F615 TOOL, wrench, Xtreme 1
Ref. Part Description Qty.
Ref. Description Part Qty.
4 PUMP Assembly 284101 284201 284251 284301 284401 1
817 PUMP, lower, A L22AC0 L29AC0 L29AC0 L29AC0 L29AC0 1
818 PUMP, lower, B L22AC0 L14AC0 L115C0 L097C0 L054C0 1
819 COUPLING, A 244819 244819 244819 244819 244819 1
820 COUPLING, B 244819 244819 247167 247167 247167 1
Ref. Description Part Qty.
- XP50-h Sprayer 284104
284105
284204
284205
284254
284255
284304
284305
284404
284405
-
4 PUMP Assembly 284102 284202 284252 284302 284402 1
817 PUMP, lower, A L14AC0 L18AC0 L180C0 L22AC0 L22AC0 1
818 PUMP, lower, B L14AC0 L090C0 L058C0 L097C0 L054C0 1
819 COUPLING, A 244819 244819 244819 244819 244819 1
820 COUPLING, B 244819 247167 247167 247167 247167 1
Ref. Description Part Qty.
- XP70-h Sprayer 284106
284107
284206
284207
284256
284257
284306
284307
284406
284407
-
4 PUMP Assembly 284103 284203 284253 284303 284403 1
817 PUMP, lower, A L090C0 L115C0 L14AC0 L14AC0 L14AC0 1
818 PUMP, lower, B L090C0 L058C0 L058C0 L048C0 L036C0 1
819 COUPLING, A 247167 247167 244819 244819 244819 1
820 COUPLING, B 247167 247167 247167 247167 247167 1
