Dimensions
90
3A0420ZAF
Floor Stand 24M281 Dimensions
Hydraulic Unit Dimensions
ti19047a
21.2 in.
(53.8 cm)
30.3 in.
(77.0 cm
)
17.8 in.
(45.1 c
m)
32.7 in.
(82.9 cm)
ti19048a
53 in.
(134.6 cm)
30.3 in.
(77.0 cm)
17.8 in.
(45.1 cm)
Shown installed on floor stand
