7
LCD display symbols and readings:
Displays the weight on the scale platform.
Unit of measurement in which the weight is indicated.
Stable weight reading: There is a weight on the platform that is not fluctuating.
Intermittent or switched off to indicate that there is movement in the scale.
Negative sign.
Weight value may be negative if a tare is activated (when pre-set tare mode).
Indicates net weight. The net weight is the real weight on the scale minus the tare. It is only
displayed if a tare has been used.
Tare activated.
The reading flashes when “normal” tare mode has been activated.
A “pre-set” tare is retained even after the weight is removed from the scale platform.
Memory pre-set tare. The current tare is a value recorded into the indicator’s memory; it could
be not necessarily a measured value.
Scale is set to zero (weigh is less than ¼ division)
Reading in high-resolution mode. It shows a division 10 times smaller than the one defined in the
weighing scale range.
Double range mode, when using the scale range 1.
Double range mode, when using the scale range 2.
The weight is below the lower limit.
The 4 segments of this indicator are activated proportionally to the difference between the
weight on the scale and the value of the lower limit. The thickest segment indicates that the
weight is lower than the value set as the lower limit in a proportion of 100% or more.
The weight is within the interval encompassed between the lower limit and the upper (high) limit.
The weight is above the upper limit.
The 4 segments of this indicator are activated proportionally to the difference between the
weight on the scale and the value of the upper limit. The thickest segment indicates that the
weight is higher than the value set as the upper limit in a proportion of 100% or more.
Battery-operated. Shows the charge level of the battery when not connected to the mains,
