765042420 Rev.000 27
Parameter overview
Freezer
Refrigera
tor
extended
Refriger
ator
Cabinet type
-22 /-10 -5/+12 +2/+12 Temperature area
45-358-
0133
45-358-
0134
45-358-
0132
GRAM sparepart item number
Para-
meter
Maxi-
mum
Mini-
mum
Value
Factory setting
SP r1 r2 °C/°F -18 5 5 Temperature setpoint
CA1 -25.0 25.0 °C/°F 0 0 0 Offset room sensor
CA2
-25.0 25.0 °C/°F 0 0 0 Offset evaporator sensor
CA3
-25.0 25.0 °C/°F
Not applicable
Offset condensor sensor
P1
0 1 - - - - 0 0 0 Celsius grade decimal point; 0=no; 1=yes
P2
0 1 - - - - 0 0 0 Temperature unit of measurement; 0=°C; 1=°F
P3
0 2 - - - - 1 1 1
Evaporator sensor function;
0= sensor absent;
1=defrosting probe and probe for evaporator fan on/off;
2=probe for evaporator fan on/off
P4 0 1 - - - - 0 # #
Enable condenser sensor 1=yes 0=no
P5
°C/°F 3 3 3
Digital Filter value (if P5 is set to a value (0= filter OFF)
, if measured temperature is inside the interval
SETPOINT-P5 and SETPOINT + P5, value shown on
the display is SETPOINT. If temperature measured is
outside previous interval, value shown on the display
will be real temperature.
P6 0 1 - - - - 1 1 1
Hysteresis type; 0=asymmetric; 1=symmetric
P8 0 250 ds 100 100 100
Display update time of temperature sensor
r0 0 15 °C/°F 2 2 2
Working setpoint differential (Hysterese)
r1
-99.0 r2 °C/°F -22 -5 2 Minimum working temperature setpoint
r2
r1 99.0 °C/°F -10 12 12 Maximum working temperature setpoint
r3
0 1 - - - - 0 0 0 Blocking setpoint calibration for user; 0=no; 1=yes
r4
0 99
0 # #
Value of set Increase after energy saving cycle
activation
r5
0 99 °C/°F 0 0 0
Decrease in temperature during Overcooling function;
see also r6
r6
0 240 min 0 0 0 Duration of Overcooling function
r7
0 99 °C/°F
# # #
minimum difference “cell temperature - working
setpoint” (when the instrument switches on) such as to
provoke the exclusion of the
consequent value of the evaporator temperature among
the ones used for the calculation of the relative average
(for the defrost activation;
onl
if d8 = 3
; also look at d17
#Notrelevantornotavailble
