COMPRESSOR PROTECTION SYSTEM
Freezer
Refrige-
rator
extended
Refrige-
rator
Cabinet type
-22 /-10 -5/+12 +2/+12 Temperature area
Para-
meter
Maxi-
mum
Mini-
mum
Value
Factory setting
C0 0 240 min 5 5 5
Delay in switching on compressor after turning on
cabinet
C1 0 240 min 5 5 5
Minimum time between two consecutive compressor
start-ups; also delay in compressor start-up after
conclusion of cell probe error ; overuled by C2+C3;
C2 0 240 min 5 5 5
Minimum duration of compressor switch off time
C3
0 240 sec 240 240 240
Minimum duration of compressor switch on time
C4
0 240 min 10 10 10
Duration of compressor switch off during room
sensor error (code “Pr1”); see also C5
C5
0 240 min 30 10 10
Duration of compressor switch on during room
sensor error (code “Pr1”); see also C4
C6
0.0 199.0 °C/°F
# # #
Condenser temperature is higher than that at which
the condenser overheating alarm is activated (code
“COH”
)
C7
0.0 199.0 °C/°F
# # #
condenser temperature is higher than the limit at
which the compressor blocked alarm is activated
(code “CSd”)
C8
0 15 min
# # # Delay for compressor alarm (code “CSd”)
C10
0 9.999 hr 2160 1440 1440
number of compressor operating hours is higher than
the limit at which the need for maintenance is
signaled (Interval for condenser/filter cleaning).
0 = function absent
#Notrelevantornotavailble

