Gram Standard Plus - Defrosting Control Parameters


765042420 Rev.000 29
DEFROSTING
Freezer
Refrige-
rator
extended
Refrige-
rator
Cabinet type
-22 /-10 -5/+12 +2/+12 Temperature area
Para-
meter
Maxi-
mum
Mini-
mum
Value
Factory setting
d0
0 99 hr 6 6 6
defrosting interval (only if d8 = 0, 1 or 2)
0= never activated
d1
0 2 - - - - 0 0 2
Defrost type
0 = Electric
1 = Hotgas
2 = Compressor stop
type of defrosting 0= ELECTRIC - during defrosting
the compressor will remain off and the defrosting
output will be activated; evaporator fan activity will
depend on parameter F2; 1=BY HOT GAS - during
defrosting the compressor will be switched on and
the defrosting output will be activated; evaporator fan
activity will depend on parameter F2; 2=VIA
STOPPING OF COMPRESSOR - during defrosting
the compressor will remain switched off and the
defrosting output will remain disactivated; evaporator
fan activit
y
will depend on parameter F2
d2
-99 99 °C/°F 12 7 4
evaporator temperature at end of defrosting (only if
P3 = 1); see also d3 valid if P3=1
d3
0 99 min 30 30 30
if P3 = 0 or 2, defrosting duration; if P3 = 1,
maximum defrosting duration; see also d2; 0= defrost
will be never activated
d4 0 1 - - - - 0 0 0
defrosting when instrument is switched on (only if d8
= 0, 1, 2 or 3) 1=yes 0=no
d5 0 99 min 30 30 30 If d4 = 1, delay in activation of defrosting after
cabinet is turned on
If d4=0 minimum time between turning on cabinet
and defrost activation
