Gram Standard Plus - Page 30


765042420 Rev.000 30
Freezer
Refrige-
rator
extended
Refrige-
rator
Cabinet type
-22 /-10 -5/+12 +2/+12 Temperature area
Para-
meter
Maxi-
mum
Mini-
mum
Value
Factory setting
d6
0 1 - - - - 1 1 1
Temperature displayed during defrosting
0= Room temperature
1= N/A
d7 0 15 min 4 4 0
Dripping duration
d8
0 4 - - - - 0 0 0
Defrosting activation criterias
0 = Interval cabinet runtime - defrosting will be
activated once the cabinet has been running for a
certain amount of time, designated as d0
1 = Interval compressor runtime - defrosting will be
activated once the compressor has been switched on
for time d0
2 = Interval evaporator temperature - defrosting will
be activated once the evaporator temperature has
been below temperature d9 for time d0
3 = Temperature - defrosting will be activated when
one of the following conditions is present :
- condition 1: “room temperature - evaporator
temperature” difference has been higher than
temperature d10 for time d12;
- condition 2: evaporator temperature has been
below temperature d9 for time d14
d9
-99 99 °C/°F
0 0 0
evaporator temperature is higher than that at which
the defrost interval counter is suspended (only if d8 =
2 or if d8 = 3 and for
condition 2
)
d11
0 1 - - - - 1 1 1
Defrosting alarm switches off once maximum time
limit has been reached (code “dFd”; only if P3 = 1
and in absence of an evaporator probe (code “Pr2”)
1 =
y
es
d15
0 99 min
0 0 0
minimum time that the compressor must be switched
on before defrosting can be activated (only if d1 = 1)
This is valid only if you have hot gas defrost
d16
0 99 min
0 0 0
Predripping duration (during predripping the
compressor will remain switched off, the defrosting
output will be activated and the
evaporator fan will remain switched off
)
d17
1 10
# # #
number of evaporator temperature values used for
the calculation of the relative average (for the defrost
activation; only if d8 = 3); also look
at r7, i11 and i12
d18
0 3.000 min
# # #
Defrosting interval (only if d8 = 3 and for condition 1)
0 = defrostin
g
for condition 1 will never be activated
d19
0 40 °C/°F
# # #
evaporator temperature above which the defrost is
activated (relative to the evaporator temperatures
average, or “evaporator temperatures
