765042420 Rev.000 34
Freezer
Refrige-
rator
extended
Refrige-
rator
Cabinet type
-22 /-10 -5/+12 +2/+12 Temperature area
Para-
meter
Maxi-
mum
Mini-
mum
Value
Factory setting
∟
0 5 - - - - 2 2 2
Effect caused by door switch activation; see also
∟4
0 = deactivated
1 = compressor and evaporator fan will be switched
off (for time
∟3 or until input is disactivated
2 = evaporator fan will be switched off (for time
∟3
or until input is disactivated)
∟
0 1 - - - - 1 1 1
Type of door switch input
0 = normally open (active input with closed contact)
1 = normally closed (active input with open contact)
∟
-1 120 min 5 5 5
Delay of door alarm (code “
∟d”)
-1= the alarm will not be signaled
∟
-1 120 min -1 -1 -1
maximum duration of the effect caused by
activation of the door switch on the compressor
and the evaporator fan
-1= the effect will last until the input is disactivated
∟
0 1 - - - - 1 1 1
storage of door alarm (code “
∟d”)
1 = yes
∟
0 6 - - - - 0 # #
Configuration multifunction input:
Not availeble / not used
∟
0 1 - - - - 0 # #
∟
0 120 min 0 # #
∟
0 15 - - - - 0 # #
∟
1 999 min # # #
∟
0 999 min 11 11 11
Time without activations of door switch needed to
automatically activate energy saving function
(condition; cabinet temperature has reached
working setpoint) (effect on the evaporator fan only
if F0 = 1 or 2)
0 = function will never be automatically activated
∟
0 240 sec # # #
minimum time door switch must be activated
(only if d8 = 3);
Not used
∟
0 240 sec # # #
minimum time door switch must be activated
(only if d8 = 3);
Not used
∟
0 240 - - - - 0 0 0
number of door switch input activations to provoke
the defrost activation
0 = the defrost will never be activated because of
the door switch input activation
∟
0 240 min 0 0 0
Minimum duration of the door switch input
activation to provoke the defrost activation
0 = the defrost will never be activated because of
the door switch input activation
#Notrelevantornotavailble
