765042420 Rev.000 35
DIGITAL OUTPUTS
Freezer
Refrige-
rator
extended
Refrige-
rator
Cabinet type
-22 /-10 -5/+12 +2/+12 Temperature area
Para-
meter
Maxi-
mum
Mini-
mum
Value
Factory setting
u1
0 6 - - - - 4
# #
operation controlled by the fourth relay output
0 = CELL LIGHT - in this case the AUXILIARY key
and parameters i0 and u2 will be activated
1 = DEMISTER RESISTORS - in this case the
AUXILIARY key and parameter u6 will be activated
2 = AUXILIARY OUTPUT - in this case the
AUXILIARY key and parameters i5 and u2 will be
activated
3 = ALARM OUTPUTS - in this case parameter u4
will be activated
4 = DOOR RESISTORS - in this case parameter
u5 will be activated
5 = EVAPORATOR VALVE - in this case
parameters u7 and u8 will be activated
6 = CONDENSER FAN - in this case parameters
P4, F11 and F12 will be activated
u2
0 1 0
# # Not available / not used
u4
0 1 0
# # Not available / not used
u5
-99 99 °C/°F 2
# #
cell temperature below that at which the door
resistors are switched on (“u5 - 2.0 °C/4 °F, only if
u1 and/or u11 = 4) (6)
u6
1 120 min
# # # Not availeble / not used
u7
0 99 °C/°F
# # # Not availeble / not used
u8
0 1 0
# # Not availeble / not used
u9
0 1 1 1 1
enabling of buzzer
1 = YES
