GRP260x Administration Guide
Version 1.0.1.18
Enables/Disables CDP “Cisco Discovery Protocol”. The default setting is
“Enabled”.
Defines the Layer 3 QoS parameter for SIP. This value is used for IP
Precedence, Diff-Serv or MPLS. The default value is 26.
Defines the Layer 3 QoS parameter for RTP. This value is used for IP
Precedence, Diff-Serv or MPLS. The default value is 46.
Enables auto configure for VLAN settings through DHCP. Disabled by default.
Enable Manual VLAN
Configuration
Enables/disables manual VLAN configuration. When this option is set to
Disabled, the phone will bypass VLAN configuration and only use the DHCP
VLAN to configure VLAN tag and priority. Default is “Enabled”.
Layer 2 QoS
802.1Q/VLAN Tag
Assigns the VLAN Tag of the Layer 2 QoS packets. The valid range is 0 –
4094.The default value is 0.
Layer 2 QoS 802.1p
Priority Value
Assigns the priority value of the Layer2 QoS packets. The valid range is 0 –
7. The default value is 0.
Maximum
Transmission Unit
(MTU)
Defines the MTU in bytes. The valid range is 576 – 1500.
The default value is 1500 bytes.
Configure the PC port mode. When set to “Mirrored”, the traffic in the LAN
port will go through PC port as well and packets can be captured by
connecting a PC to the PC port. The default setting is “Enabled”.
Assigns the VLAN Tag of the PC port. The valid range is 0 – 4094.
The default value is 0.
Assigns the priority value of the PC port. The valid range is 0 – 7.
The default value is 0.
Specifies the HTTP proxy URL for the phone to send packets to. The proxy
server will act as an intermediary to route the packets to the destination.
Specifies the HTTPS proxy URL for the phone to send packets to. The proxy
server will act as an intermediary to route the packets to the destination.
