FIRMWARE VERSION 1.0.8.4 GXP1100/GXP1105 USER MANUAL Page 34 of 53
users, it is recommended to use the default setting, as incorrect settings may
influence the audio quality.
G723 Rate
Selects encoding rate for G723 codec. The default value is 5.3kbps.
G.726-32 Packing Mode
Selects "ITU" or "IETF" for G726-32 packing mode.
iLBC Frame Size
Selects iLBC packet frame size. The default value is 30ms.
iLBC Payload Type
Specifies iLBC Payload type. The default value is 97. The valid range is
between 96 and 127.
Jitter Buffer Type
Selects either Fixed or Adaptive based on network conditions. The default
setting is "Adaptive".
Jitter Buffer Length
Selects Low, Medium, or High based on network conditions. The default
setting is "Medium".
Account 1 -> Call Settings
Early Dial
Selects whether or not to enable early dial. If it's set to "Yes", the SIP proxy
must support 484 response. The default setting is "No".
Dial Plan Prefix
Sets the prefix added to each dialed number.
Dial Plan
A dial plan establishes the expected number and pattern of digits for a
telephone number. This parameter configures the allowed dial plan for the
phone.
Dial Plan Rules:
1. Accepted Digits: 1,2,3,4,5,6,7,8,9,0 , *, #, A,a,B,b,C,c,D,d;
2. Grammar: x - any digit from 0-9;
a) xx+ or xx. - at least 2 digit numbers
b) xx - only 2 digit numbers
c) ^ - exclude
d) [3-5] - any digit of 3, 4, or 5
e) [147] - any digit of 1, 4, or 7
f) <2=011> - replace digit 2 with 011 when dialing
g) | - the OR operand
 Example 1: {[369]11 | 1617xxxxxxx}
Allow 311, 611, and 911 or any 10 digit numbers with leading digits 1617;
 Example 2: {^1900x+ | <=1617>xxxxxxx}
Block any number of leading digits 1900 or add prefix 1617 for any dialed 7
digit numbers;
 Example 3: {1xxx[2-9]xxxxxx | <2=011>x+}
