FIRMWARE VERSION 1.0.5.24 GXP2120/GXP2110/GXP2100/GXP14xx USER MANUAL Page 43 of 77
DEFINITIONS
This section describes the options in the phone's Web GUI. As mentioned, you can log in as an
administrator or an end user.
 Status: Displays the Account status, Network status, and System Info of the phone;
 Account: To configure the SIP account;
 Network: To configure network settings;
 Settings: To configure call features, ring tone, LCD display, Web services, XML applications,
programmable keys, and etc;
 Maintenance: To configure web/Telnet access, upgrading and provisioning, language settings,
TR-069, security and etc.
 Phonebook: To manage Phonebook and LDAP.
STATUS PAGE DEFINITIONS
Status -> Account Status
Account x
Account index.
SIP User ID
Displays the configured SIP User ID.
SIP Server
Displays the configured SIP Server address.
SIP Registration
Displays SIP registration status YES/NO.
Status -> Network Status
MAC Address
Global unique ID of device, in HEX format. The MAC address will be used for
provisioning and can be found on the label coming with original box and on the
label located on the back of the device.
IP Setting
DHCP, Static IP or PPPoE.
IPv4 Address
The IPv4 address obtained on the phone.
IPv6 Address
The IPv6 address obtained on the phone.
Subnet Mask
The subnet mask obtained on the phone.
Gateway
The gateway address obtained on the phone.
DNS Server 1
The DNS server address 1.
DNS Server 2
The DNS server address 2.
PPPoE Link Up
PPPoE connection status.
NAT Traversal
NAT traversal status for each account.
Status -> System Info
