FIRMWARE VERSION 1.0.5.24 GXP2120/GXP2110/GXP2100/GXP14xx USER MANUAL Page 66 of 77
Phonebook -> Phonebook Management
Enable Phonebook XML
Download
Configures to enable phonebook XML download. Users could select
HTTP/HTTPS/TFTP to download the phonebook file. The default setting is
"Disabled".
Phonebook XML Server
Path
Configures the server path to download the phonebook XML. This field could
be IP address or URL, with up to 256 characters.
Phonebook Download
Interval
Configures the phonebook download interval (in minutes). If it's set to 0, the
automatic download will be disabled. The default value is 0. The valid range is
5 to 720 minutes.
Remove Manually-edited
Entries on Download
If set to "Yes", when XML phonebook is downloaded, the entries added
manually will be automatically removed. The default setting is "Yes".
Download XML
Phonebook
Click on "Download" to download the XML phonebook file to local PC.
Upload XML Phonebook
Click on "Upload" to upload local XML phonebook file to the phone.
Phonebook -> LDAP
Server Address
Configures the IP address or DNS name of the LDAP server.
Port
Configures the LDAP server port.
Base
Configures the LDAP search base. This is the location in the directory where
the search is requested to begin.
Example:
dc=grandstream, dc=com
ou=Boston, dc=grandstream, dc=com
User Name
Configures the bind "Username" for querying LDAP servers. Some LDAP
servers allow anonymous binds in which case the setting can be left blank.
Password
Configures the bind "Password" for querying LDAP servers. The field can be
left blank if the LDAP server allows anonymous binds.
LDAP Number Filter
Configures the filter used for number lookups.
Examples:
(|(telephoneNumber=%)(Mobile=%) returns all records which has the
"telephoneNumber" or "Mobile" field starting with the entered prefix;
(&(telephoneNumber=%) (cn=*)) returns all the records with the
"telephoneNumber" field starting with the entered prefix and "cn" field set.
LDAP Name Filter
Configures the filter used for name lookups.
Examples:
(|(cn=%)(sn=%)) returns all records which has the "cn" or "sn" field starting
with the entered prefix;
