FIRMWARE 1.0.4.4 GXW42XX USER MANUAL PAGE 13 OF 57
FIGURE 2: 50 PIN TELCO CONNECTOR
NOTE:
For GXW4216, only first 16 pairs are connected.
For GXW4232, first 24 pairs on 1
st
RJ21 connector and first 8 pairs on the 2
nd
RJ21 connector are
connected.
For GXW4224 and GXW4248, the last pair of pin 25 and 50 on each RJ21 is not connected.
All LED lights display green when ON.
LINK LED and ACT LED blinking in following status indicate different network speed.
10M: LINK and ACT all blink, ACT blinks faster then LINK
100M: LINK and ACT all blink, ACT blinks the same fast as LINK
1000M: LINK does not blink, only ACT blink
Slow blinking of FXS LED together indicates a firmware upgrade or provisioning state.
