FIRMWARE 1.0.4.4 GXW42XX USER MANUAL PAGE 51 OF 57
Ring Tones
Configure ring cadences according to preference.
TABLE 11: FXS PORTS
Port Settings
SIP User ID
User account information, provided by VoIP service provider (ITSP).
Usually in the form of digit similar to phone number or actually a
phone number.
Authenticate ID
SIP service subscriber’s Authenticate ID used for authentication.
Can be
identical to or different from SIP User ID.
Password
SIP service subscriber’s account password for GXW42XX to register
to (SIP) servers of ITSP.
Name
Any name to identify this specific user.
Profile
Select the corresponding Profile ID (1/2/3/4)
Enable FXS (TR-069)
Enable or disable the FXS port.
Advanced Port
Settings
Offhook Auto-dial
Configure an auto dial number when offhook.
Hunting Group
Assign this port to a certain hunting group
FXO Mapping
Map to FXO Port #
This is used only when peering with a Grandstream GXW410x.
Default 1, Supported values are 1-8, meaning line 1 to 8 of the
GXW410x device where the port will be mapped to.
Map to FXO Gateway
IP
This is used when peering with an FXO gateway of any brand. You
have to specifically mention the IP and sip port where call will be sent
to.
And Port
Sip port that will be annexed to the IP address above.
SAVING THE CONFIGURATION CHANGES
After user makes a change to the configuration, press the “Update” button in the Configuration Menu. The
web browser will then display a message window to confirm saved changes.
Grandstream recommends reboot or power cycle the gateway after saving changes.
