UCM6100 Series CDR and REC API Guide
API CONFIGURATION
The UCM6100 supports third party billing interface API for external billing software to access CDR and
call recording files on the PBX. The API uses HTTPS to request the CDR data and call recording data
matching given parameters as configured on the third party application.
API CONFIGURATION
Before accessing the CDR API (to access call detail records) and REC API (to access call recording files),
the administrators need enable API and configure the access/authentication information on the UCM6100
first.
Table 2: API Configuration Parameters
Enable/Disable API. The default setting is disabled.
Configure the IP address for TLS server to bind to. "0.0.0.0" means binding to all
interfaces. The port number is optional and the default port number is 8443. The IP
address must match the common name (host name) in the certificate so that the
TLS socket won't bind to multiple IP addresses. The default setting is 0.0.0.0:8443.
Upload TLS private key. The size of the key file must be under 2MB. This file will
be renamed as 'private.pem' automatically.
Upload TLS cert. The size of the certificate must be under 2MB. This is the
certificate file (*.pem format only) for TLS connection. This file will be renamed as
"certificate.pem" automatically. It contains private key for the client and signed
certificate for the server.
Configure the user name for TLS authentication. If not configured, authentication
will be skipped.
TLS Authentication
Password
Configure the password for TLS authentication. This is optional.
Specify a list of IP addresses permitted by CDR and REC API. This creates an API-
specific access control list. Multiple entries are allowed.
For example, "192.168.40.3/255.255.255.255" denies access from all IP addresses
except 192.168.40.3.
The default setting is blank, meaning all IP addresses will be denied.
