UCM6XXX Basic Configuration Guide
OVERVIEW
This document will provide instructions on how to set up a UCM6XXX series from an out of the box state to a
fully functional state. This includes design considerations, creating user extensions, provisioning endpoints with
Zero-Config, conferencing, auto attendant configuration, analog/VoIP trunks, routing inbound/outbound calls
and voicemail/fax to email setup.
For detailed information in regard to parameters that are encountered in this guide, please check one of the
UCMs User Manual.
SETUP GUIDE SCENARIO
The image below shows the most typical setup where you have the UCM6XXX series WAN port connected to
the Internet and the LAN side of the UCM6XXX series providing DHCP.
We will use this scenario to setup a Grandstream GXP2135 which will be connected to the LAN side of the
UCM6xx series. There can also be a network switch connected to the LAN port of the UCM6xxx series so that
there may be more than one device connected.
Figure 1: Typical UCM6xx Scenario
