Grandstream Networks UCM6304A User Manual

P a g e | 131
UCM630xA Series User Manual
Version 1.0.9.10
Max Hits
Specify the maximum number of results to be returned by the LDAP server.
Valid range is 1 to 3000. The default value is 50.
Search Timeout
Specify the interval (in seconds) for the server to process the request and
client waits for server to return. Valid range is 0 to 180. Default value is 30.
Sort Results
Specify whether the searching result is sorted or not. Default setting is No.
Incoming Calls
Configure to enable LDAP number searching when receiving calls. The
default setting is No.
Outgoing Calls
Configure to enable LDAP number searching when making calls. The
default setting is No.
Lookup Display Name
Configures the display name when LDAP looks up the name for incoming
call or outgoing call.
It must be a subset of the LDAP Name Attributes.
XML Phonebook
Phonebook XML Server
Select the source of the phonebook XML server.
 Disable
Disable phonebook XML downloading.
 Manual
Once selected, users need specify downloading protocol HTTP,
HTTPS or TFTP and the server path to download the phonebook XML
file. The server path could be IP address or URL, with up to 256
characters.
 Local UCM Server
Once selected, click on the Server Path field to upload the phonebook
XML file. Please note after uploading the phonebook XML file to the
server, the original file name will be used as the directory name and
the file will be renamed as phonebook.xml under that directory.
Phonebook Download
Interval
Configure the phonebook download interval (in Minute). If set to 0,
automatic download will be disabled. Valid range is 5 to 720.
