If the protocol or port has been changed, the user will be logged out and redirected to the new URL.
Network Settings
After successfully connecting the UCM630xA to the network for the first time, users could login the Web GUI and
go to System SettingsNetwork Settings to configure the network parameters for the device.
 UCM630xA supports Route/Switch/Dual mode functions.
In this section, all the available network setting options are listed for all models. Select each tab in Web
GUISystem SettingsNetwork Settings page to configure LAN settings, WAN settings, 802.1X and Port
Forwarding.
Basic Settings
Please refer to the following tables for basic network configuration parameters on UCM6300A, UCM6302A,
UCM6304A and UCM6308A, respectively.
Table 9: UCM630xA Network SettingsBasic Settings
Method
Select "Route", "Switch" or "Dual" mode on the network interface of UCM630xA. The
default setting is "Switch".
 Route
WAN port will be used for uplink connection. LAN port will function similarly to a regular
router port.
 Switch
WAN port will be used for uplink connection. LAN port will be used as a bridge for
connections.
 Dual
Both WAN and LAN ports will be used for uplink connections labeled as LAN2 and
LAN1, respectively. The port selected as the Default Interface will need to have a
gateway IP address configured if it is using a static IP.
MTU
Specifies the maximum transmission unit value. Default is 1492.
