UCM6510 CDR Report and CDR API Guide
CDR API CONFIGURATION FILES
The UCM6510 supports third party billing interface API for external billing software to access CDR on the
PBX starting from firmware version 1.0.6.x. The API uses HTTPS to request the CDR data matching
given parameters as configured on the third party application.
CDR API CONFIGURATION
Before accessing the API, the administrators need enable API and configure the access/authentication
information on the UCM6510 first.
Table 2: CDR API Configuration Files
Enable/Disable CDR API. The default setting is disabled.
Configure the IP address for TLS server to bind to. "0.0.0.0" means binding to all
interfaces. The port number is optional and the default port number is 8443. The IP
address must match the common name (host name) in the certificate so that the
TLS socket won't bind to multiple IP addresses. The default setting is 0.0.0.0:8443.
Upload TLS private key. The size of the key file must be under 2MB. This file will
be renamed as 'private.pem' automatically.
Upload TLS cert. The size of the certificate must be under 2MB. This is the
certificate file (*.pem format only) for TLS connection. This file will be renamed as
"certificate.pem" automatically. It contains private key for the client and signed
certificate for the server.
Configure the user name for TLS authentication. If not configured, authentication
will be skipped.
TLS Authentication
Password
Configure the password for TLS authentication. This is optional.
Specify a list of IP addresses permitted by CDR API. This creates an AIP-specific
access control list. Multiple entries are allowed.
For example, "192.168.40.3/255.255.255.255" denies access from all IP addresses
except 192.168.40.3.
