12. Mount the magnetic sensor on the motor.
13. Mount the motor on is bracket.
14. Hold up the motor so the treads on the coupling meet the
treads of the shaft. Turn the wash basket wheel clock wise
until the threads of the shaft is fully in the coupling.
15. Connect the motor and magnetic sensor electrically.
i. Exchange of wash ware sensor.
1. Secure the hood with the safety pin.
2. Mark the position of the feet.
3. Move the machine out so that the back is accessible.
4. Undo the back plate.
5. Undo the sensor head by unscrewing it from the housing.
(Right hand threads.)
6. Gently pull out the connector and disconnect the cable.
7. Connect the cable and gently pull the cable as the sensor is put
back into the housing, this to avoid that the cables are jammed
in the treads.
8. Put stretch the cable and bundle it so no loops can get caught
by the hood mechanism.
9. Put the machine back in its original place, check levelling and
hood alignment.
10. Check function of the wash ware sensor.
2. Hood
a. Adjustment of hood.
Make sure that the machine is in level.
1. Adjust feet until machine is totally in level.
Check left. right and front.
