3.2 Cleaning inside the machine 3 Daily cleaning
3.2 Cleaning inside the machine
11 Press STOP button (2) and open drain valve to empty wash tank.
22 Switch off at the main electrical switch.
Fig. 23 Removing spray pipe
Fig. 24 Cleaning wash nozzles
33 Remove and check both
spray pipes.
• Push the spray pipe in and
turn counter-clockwise.
• Pull it straight out.
If any visible piece of e.g
chicken bone is seen in the
opening of the nozzle, take
the back side of a tea spoon
and carefully put the piece
back into the spray pipe. Any
pieces will then fall down and
out at the end.
See Fig. 23 Removing spray
pipe and
See Fig. 24 Cleaning wash
nozzles
Fig. 25 Tank grids
44 Lift the two tank grids by the
handles. Clean and flush both
grids with water.
See Fig. 25 Tank grids
Rev. 2021-12 33
