Bottom Panel
Top Panel
Input/output cable for GL
(Cable is the option B-513)
Humidity sensor
(Option: when using the B-530)
USB interface terminal
Operation status LED
SD memory card
Control panel keys
External input/output terminals
GND terminal
Power jack for humidity sensor
Analog signal input terminals
AC adapter jack
Battery pack can be installed
(Battery pack is the option B-573)
Power switch
Tilt foot
Battery cover
Label
Wireless LAN
connection terminal
Wireless unit
(Option: when using the B-568)
3
Nomenclature
• POWER
• START
• CHARGE
• LOGIC/PULSE
• EXT TRIG/SAMPLE
• ALARM
To Next Page
