Bottom Panel
3
Name of parts
• Standard 20CH screw terminal (B-563)
• Standard 20CH screwless terminal (B-563SL)
• Standard 30CH screwless terminal (B-563SL-30)
• Withstand high-voltage high-precision terminal (B-565)
Top Panel
Front Panel
Operation status LED
SD memory card
Power switch
Label
Battery cover
Battery pack can be installed
(Battery pack is the option B-573)
AC adapter jack
GND terminal
Control panel keys
Monitor
USB interface terminal
LAN interface terminal
Wireless LAN
connection terminal
Wireless unit
(Option: when using the B-568)
Input/output cable for GL
(Cable is the option B-513)
External input/output terminals
• LOGIC/PULSE
• EXT TRIG/SAMPLE
• ALARM
Analog signal input terminals
Humidity sensor
(Option: when using the B-530)
Power jack for humidity sensor
Tilt foot
• POWER
• START
• CHARGE
