Graphy Tera Harz Cure - Page 11

11 / 25
□ Nitrogen generator installation (when added)
Place the Nitrogen Generator on top of the
Tera Harz Cure and attach the Fix Bracket..
Attach the Hose Module as shown in the picture.
Push it all the way in to prevent air leakage.
Connect the air line after assembling the air
filter module with the included bolts as
shown in the picture.
Connect the compressed air hose coming from
outside as shown in the picture. (Ø6)
Nitrogen generator installation completed
