July 3, 2007 K2 Storage System Instruction Manual 143
Setting up the L3 RAID chassis
Do not swap Expansion chassis or otherwise reconfigure storage. If you connect a
L3 RAID Expansion chassis to the wrong controller such that the Expansion
chassis contains disk modules that were bound using a different controller you will
lose your media file system.
On each L3 RAID Expansion Chassis
(if installed) set the same chassis address
on both Expansion adapters.
1
Chassis Address
on RAID Chassis
is pre-set. Do not
attempt to change
this setting.
Chassis
Address = 2
Chassis
Address = 1
Chassis
Address = 0
3
Chassis
Address = 3
3
Chassis
Address = 3
2
Chassis
Address = 2
1
Chassis
Address = 1
0
Chassis
Address = 0
2
DL0
DL1
L3 RAID
Chassis
Expansion
Chassis 2
Expansion
Chassis 4
Expansion
Chassis 6
Expansion
Chassis 7
Expansion
Chassis 5
Expansion
Chassis 3
Expansion
Chassis 1
These Expansion Chassis connected to DL0
These Expansion Chassis connected to DL1
