SAFETY SYMBOLS
This Safety Alert Symbol means ATTENTION!
BECOME ALERT! YOUR SAFETY IS IN-
VOLVED! In this manual, the safety alert symbol
identifies potential hazards and alerts the reader to
safety messages. These hazards may cause serious
injury or death if you do not follow the recom-
mended precautions in the safety messages.
Throughout this manual the word IMPORTANT
provides special mechanical specifications or infor-
mation and is used to indicate that failure to observe
can cause damage to equipment. The word NOTE
emphasizes general information requiring special at-
tention.
51
5
3
1
6
4
2
GREEN
BLACK
BLACK
PURPLE
GROUND TO ENGINE
FUSE BLOCK
YELLOW/BROWN
CAB
CBA
BLACK
RED
YELLOW
OPTIONAL HYDRAULIC LIFT WIRING DIAGRAM
ItemItem
ItemItem
Item
OrderOrder
OrderOrder
Order
DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
No.No.
No.No.
No.
1 144950 Hydraulic Solenoid
2 183710 Tilt Switch
3 183940 Push Button Switch
4 184973 Weather Pack Connector
5 181460 Accessory Fuse - 7.5 amp Auto
6 722747 Mount - Tilt Switch

Grasshopper 721D2 Specifications

General

Brand	Grasshopper
Model	721D2
Category	Lawn Mower
Language	English
