GRAUPNER Falcon 12 User Manual

9 / 52
S1019_S1034_S1035_33579_33583_FW2_DE_V1.0sh
GR-24 PRO HoTT
No. 33583
Temperature range - 15...+70 °C
Antenna length 2 x wire 145 mm
Total weight approx.: 18 g
Frequency 2400 ... 2483.5 MHz
Dimensions approx. 46 x 31 x 14 mm
Modulation 2.4 GHz FHSS
Power consumption 70 mA
Operating voltage (2.5) 3.6 ... 8.4 V
3-axis gyro yes
Vario yes
Switch between
"Pulse" and "Level"
from transmitter
yes
Connection table
Updates /
Telemetry
sensors
SUMDIN SUMD Optional voltage
measurement
S1019.AIR T/9 --- C6 C9
S1034 C5 C6 C5 C5
S1035 C5 C6 C5 C5
33579 T/9 --- C6 C9
33583 T C10 C8 ---
