10
PTO CONTROL
Model 985114, 115, 117, 119, 307, 309, 311, 312, 313
Item Part No. Qty. Description
1 010683 1 Handle-Rubber Shifter
2 046798 1 Rod-Shifter
3 041042 1 Spring-Tension .041 x 1.25 x .50
4 06529600 1 Nut-Locking-Center .375-16 Grade 2
5 06436200 8 Washer-Flat-Steel .406 x .812 x .065
6 06529700 4 Nut-Locking-Center .250-20 Grade 2
7 06437300 4 Washer-Flat-Steel .281 x .620 x .065
8 040637 2 Cam-Shifter
9 05947700 2 Bolt-Hex .25-20 x 1.00 Grade 5
10 040599 1 Spring-Compression .081 x .720 x 2.75
11 05952500 2 Bolt-Hex .25-20 x 1.50 Grade 5
12 032353 2 Block-Shift Lever
13 046784 1 Link-Shifter Stop
14 039078 2 Spring Washer
15 06707300 2 Pin-Cotter .12 x .75
16 040849 1 Weldment, PTO Bellcrank
17 08573000 1 Rod-PTO
18 120369 1 Nut-Hex .375-24 Grade 2
19 02917100 1 Ball Joint
20 06538800 1 Nut-Locking Nylon .375-24 with Insert
21 021462 1 Shim-Mower Height Adjuster Bracket
PH0051
1
2
3
4
5
6
7
8
8
5
9
10
5
11
12
7
6
13
5
14
5
15
5
16
5
14
17
18
19
20
21
