34
WIRING DIAGRAM
Model 985115, 117, 307, 309, 311, 312
Item Part No. Qty. Description
1 08255700 1 Engine, Robin (115, 307)
08255800 1 Engine, Robin (117, 309, 311, 312)
2 00524600 1 Fuse 30 AMP
3 03602300 1 Key Switch
4 038256 1 Hour Meter
5 02743300 1 Start Cable 22"
6 044766 1 Solenoid
7 02727200 1 Starter Cable 13" - Battery to Solenoid
8 03621100 1 Battery with Tube (307, 309, 311, 312)
01554800 1 Battery (115, 117)
9 09222700 1 Cable, Negative Battery 35"
10 03081700 1 Molded Diode Plug- Clear 1 AMP
11 040216 1 Relay
12 08591000 1 Harness, Handlebar
13 046823 3 Switch
14 08594200 1 Harness, Steering Brake
15 051919 1 Switch, Interlock Closed (Forward/Reverse)
16 051918 1 Switch, Interlock Open (PTO)
BLACK
AB
RELAY
KEY
SWITCH
FUSE
1
2
2
1
2
LEFT PRESENCE
CONTROL SWITCH
1
RIGHT PRESENCE
CONTROL SWITCH
FWD/REV INTERLOCK
SWITCH
BATTERY
BLACK
A
B
M
S1
G
1
2
3
4
1
2
3
4
4
3
1
2
4
3
2
1
RED
RED
DIODE
2
1
BROWN
WHITE/BLACK
PURPLE
2
1
BLACK
STEERING BRAKE PRESENCE
CONTROL SWITCH
1
2
1
2
BROWN/YELLOW
ENGINE
DETECTOR
REGULATOR
MAGNETO KILL
BLACK
BLACK
YELLOW/RED
BLACK
BLACK
RED/YELLOW
RED/YELLOW
BLACK
RED/YELLOW
RED/YELLOW
RED
PURPLE
STARTER
YELLOW/RED
BROWN/YELLOW
S2
PTO SWITCH
30
86 85
87
87a
BLACK
HOUR
METER
+
-
STARTER
SOLENOID
COIL 2 COIL 1
RED
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
13
15
16
PH0351
