(continued from previous page)
// Enable SGPIO pin outputs.
LPC_SGPIO->GPIO_OENREG =
(1L << 12) | // SGPIO12
(1L << 0); // SGPIO0
// SGPIO pin 0 outputs slice A bit 0.
LPC_SGPIO->OUT_MUX_CFG[0] =
(0L << 4) | // P_OE_CFG = X
(0L << 0); // P_OUT_CFG = 0, dout_doutm1 (1-bit mode)
// SGPIO pin 12 outputs slice D bit 0.
LPC_SGPIO->OUT_MUX_CFG[12] =
(0L << 4) | // P_OE_CFG = X
(0L << 0); // P_OUT_CFG = 0, dout_doutm1 (1-bit mode)
// Slice A
LPC_SGPIO->SGPIO_MUX_CFG[0] =
(0L << 12) | // CONCAT_ORDER = 0 (self-loop)
(1L << 11) | // CONCAT_ENABLE = 1 (concatenate data)
(0L << 9) | // QUALIFIER_SLICE_MODE = X
(0L << 7) | // QUALIFIER_PIN_MODE = X
(0L << 5) | // QUALIFIER_MODE = 0 (enable)
(0L << 3) | // CLK_SOURCE_SLICE_MODE = 0, slice D
(0L << 1) | // CLK_SOURCE_PIN_MODE = X
(0L << 0); // EXT_CLK_ENABLE = 0, internal clock signal (slice)
LPC_SGPIO->SLICE_MUX_CFG[0] =
(0L << 8) | // INV_QUALIFIER = 0 (use normal qualifier)
(0L << 6) | // PARALLEL_MODE = 0 (shift 1 bit per clock)
(0L << 4) | // DATA_CAPTURE_MODE = 0 (detect rising edge)
(0L << 3) | // INV_OUT_CLK = 0 (normal clock)
(0L << 2) | // CLKGEN_MODE = 0 (use clock from COUNTER)
(0L << 1) | // CLK_CAPTURE_MODE = 0 (use rising clock edge)
(0L << 0); // MATCH_MODE = 0 (do not match data)
LPC_SGPIO->PRESET[0] = 1;
LPC_SGPIO->COUNT[0] = 0;
LPC_SGPIO->POS[0] = (0x1FL << 8) | (0x1FL << 0);
LPC_SGPIO->REG[0] = 0xAAAAAAAA; // Primary output data register
LPC_SGPIO->REG_SS[0] = 0xAAAAAAAA; // Shadow output data register
// Slice D (clock for Slice A)
LPC_SGPIO->SGPIO_MUX_CFG[3] =
(0L << 12) | // CONCAT_ORDER = 0 (self-loop)
(1L << 11) | // CONCAT_ENABLE = 1 (concatenate data)
(0L << 9) | // QUALIFIER_SLICE_MODE = X
(0L << 7) | // QUALIFIER_PIN_MODE = X
(0L << 5) | // QUALIFIER_MODE = 0 (enable)
(0L << 3) | // CLK_SOURCE_SLICE_MODE = 0, slice D
(0L << 1) | // CLK_SOURCE_PIN_MODE = X
(0L << 0); // EXT_CLK_ENABLE = 0, internal clock signal (slice)
(continues on next page)
