HackRF
P21 Analog
Pin Function
1 GND
2 ADC0_6
3 GND
4 ADC0_2
5 GND
6 ADC0_5
7 GND
8 ADC0_0
P22 I2S
Pin Function
1 VCC
2 I2S0_TX_SDA
3 I2S0_TX_WS
4 I2S0_TX_SCK
5 I2S0_TX_MCLK
6 GND
P25 LPC_ISP
Pin Function
1 GND
2 ISP
3 NC
4 U0_RXD
5 U0_TXD
6 RESET
P26 LPC_JTAG
Pin Function
1 VCC
2 TMS
3 GND
4 TCK
5 GND
6 TDO
7 NC
8 TDI
9 GND
10 RESET
78 Chapter 21. Jawbreaker
