Air Handlers
8
4 Installation
4.1 Unit Inspection
Upon delivery, inspect the unit for damage. Any damage must be reported
immediately to the carrier. Do not install such an equipment damaged by freight
which determines the integrity and safety of the unit.
Please check the equipment model number to ensure the unit is appropriately
sized for the condensing unit.
If an incorrect unit is supplied, it must not be installed and it is to be returned to
the supplier. The manufacturer assumes no responsibility for the installation of
incorrectly delivered units. The evaporator coil contains high-pressure inert gas for
holding charge.
4.2 Location
This air handler is designed for indoor installation only. Do not
install it outdoors.
When installing the air handler, take consideration to minimize the length of
refrigerant tubing as much as possible. Do not install the air handler in a location
either above or below the condenser that violates the instructions provided with the
condenser. Service clearance is to take precedence. Allow a minimum of 24” in front
of the unit for service clearance. When installing in an area directly over a finished
ceiling (such as an attic), an emergency drain pan is required directly under the unit.
See local and state codes for requirements. When installing this unit in an area that
may become wet, elevate the unit with a sturdy, non-porous material. In installations
that may lead to physical damage (i.e. a garage) it is advised to install a protective
barrier to prevent such damage.
This air handler is designed for a complete supply and return ductwork system.
Do not operate this product without all ductwork attached.
Based upon the actual conditions, if air handler is installed as Fig. A or Fig. B
make sure that there is enough space for care and maintenance and the air
handler is not accessible to the general public.
