UNIT INSTALLATION
37
1. SELECTION THE MOUNTING POSITION
Especially, the installation place is very important for the fan coil unit because it is very difficult to
move from placc aftr the first installation.
Decide the mounting position together with the customer as follows:
The discharge direction can be selected as shown below.
Since 2 -way outlet causes performance problems, do not set it .
Install the indoor unit on a place having a sufficient strength so that it with stands against the weight of
the unit.
The inlet and outlet ports should not be obstructed; the air should be able to blow all over the room.
Leave the space required to service the air conditioner.
The ceiling rear height is 9-3/8 " inches(250mm) or more.
A place from where the air can be distributed evenly throughout the room by the unit.
A place from where drainage can be extracted outdoor easily.
