Gree FP-85XD/B-T Service Manual

Unit MAINTENANCE
61
NO.
Discription
FP-8XD-E
FP-10XD-E
FP-12.5XD-E
Quantit
y
EM52000050
EM52000060
EM52000030
Name of Parts
Part Code
Part Code
Part Code
1
Tube Exit plate
02217102
02217102
02217102
1
2
Body Fixing Plate
01332701
01332701
01332701
4
3
Front Side Plate
01302718
01302718
01302718
1
4
Left Side Plate
01302715
01302715
01302715
1
5
Base Plate
01222701
01222701
01222701
1
6
Rear Side Plate
01302714
01302714
01302714
1
7
Bottom Foam
52012722
52012722
52012722
1
8
Motor Gasket
76712711
76712711
76712711
4
9
Bolt M6
70212711
70212711
70212711
4
10
Motor Support
01702701
01702701
01702701
1
11
Motor
15012703
15012703
15012703
1
12
Electric Heater
32002701
32002701
32002701
1
13
Centrifugal Fan
10312705
10312705
10312705
1
14
Evaporator Linkage
01074042
01074042
01074042
1
15
Cable-cross Loop
76512701
76512701
76512701
1
16
Tube sensor
3900012125
3900012125
3900012125
1
17
sensor insert B
42020063
42020063
42020063
1
18
Heat exchanger
01127104
01127104
01127104
1
19
Water Tray Assy
20182701
20182701
20182701
1
20
Rubber Stem
76712701
76712701
76712701
1
21
Electric Base Plate
01412722
01412721
01412721
1
22
Flow-guide Loop
10372701
10372701
10372701
1
23
Electric Box
20102701
20102701
20102701
1
24
Wire Clamp
71010102
71010102
71010102
4
25
Terminal Board
42011142
42011142
42011142
1
26
relay
44010206
44010206
44010206
1
27
Transformer
43110170
43110170
43110170
1
28
Electric Box Cover I
20102702
20102702
20102702
1
29
Room sensor
39000110
39000110
39000110
1
30
Remote Controller
30512506
30512506
30512506
1
