Gree GMV-24WL/C-T

GREE DC Inverter Side Discharge VRF Ⅱ for North America
116
Removal operation for panel
Remark: Before removing the panel, please make sure that the unit is disconected with the power
Process
Operation Instruction
2. Remove front
side plate
sub-assy
● Loose the screw fixing the front
side plate with screwdriver
● Hold the front side plate
upwards and then put it on the
floor flatly
3. Remove front
panel and grille
● Loose the screws fixing the
front panel and grille with
screwdriver
● Put the front panel and grille on
the floor flatly
4. Remove left
side plate and
rear side plate
● Loose screws fixing left side
plate and rear side plate with
screwdriver
● remove the rear side plate
