Gree GMV-ND56PHS/A-T User Manual

Multi Variable Air Conditioners Duct Type Indoor Unit
4
Note!
① √: included, X: not included
②
Please refer to the user manual of Wired Controller or Remote Controller for function
details
3 Preparations for Installation
Note: Product graphics are only for reference. Please refer to actual products. Unspecified
measure unit is mm/inch.
3.1 Standard Fittings
Please use the supplied standard fittings listed below as instructed.
No.
Name
Appearance
Q'ty
Usage
1
Wired Controller
1
To control the indoor unit
2
M4X25 Screw
(Cross recessed small
pan head screw)
3
To fix the wired controller
3
Drain Hose Assembly
1
To connect with the hard PVC
drain pipe
4
Special Nut
1
To be used for connecting the
refrigerant pipe
5
M10X8 Nut with Washer
4
To be used together with the
hanger bolt for installing the unit.
6
M10 Nut (M10X8.4 Nut)
4
To be used together with the
hanger bolt for installing the unit.
7
M10 Washer (Spring
Washer M10X2.6)
4
To be used together with the
hanger bolt for installing the unit.
8
Insulation
1
To insulate the gas pipe
9
Insulation
1
To insulate the liquid pipe
10
Fastener
8
To fasten the sponge
11
Hanger
or
4
To fix the indoor unit
12
Nut with Washer
8
To fix the hook on the cabinet of
the unit.
13
paper pattern for
installation
1
Locate the drill hole on ceiling
