A/A DC INVERTER U-MATCH AIR CONDITIONERS MAINTENANCE
239
Spare Parts List
NO. Name of Part Name Code Qty
1 Filter Sub-Assy '11125303 2
2 Left Side Plate Assy '01315293 1
3 Top Cover Assy '01265301 1
4 Ambient Temperature Sensor '3900012123 1
5 Tube sensor '3900012128 1
6 Electric Box Assy '01395777 1
7 Main Board '30228205 1
8 Transformer '43110239 1
9 Capacitor CBB61 '33010014 1
10 Terminal Board
0
11 Terminal Board '42010194 1
12 Display Board '30294219 1
13 Signal Wire 40010232 1
14 Water Tray Assy '01285317 1
15 Bottom Cover Assy '01265304 1
16 Fan Assy (right) '15012458 1
17 Fan Motor '15705304 1
18 Fan Fixed Plate Assy '01325301 1
19 Fan Assy (left) '15012454 1
20 Evaporator Assy '01025387 1
21 Right Side Plate Assy '01315304 1
Model:GFH36K3CI/GFH42K3CI
Exploded View
To Next Page
