Service Manual
Installation and Maintenance
38
Fig. 6 – Shipping Tape Location
Remove shipping
screw if present
Fig. 7 – Shipping Screw Location
Fig. 8 – Removing Front Panel
Fig. 9 –Securing Unit
UNIT DAMAGE HAZARD
Failure to follow this caution may result in equipment
damage or improper operation.
Failure to remove shipping tape and screw will prevent
fresh air vent door from opening and may result in damage
to vent door cable.
CAUTION
!
Shipping
tape
