Service Manual
Technical Information
6
Parameter Unit Value
Model ETAC2-12HC230VA-A ETAC2-12HP230VA-A
Product Code CC060045300_L45468 CC060045400_L45468
Power Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Cooling Capacity Btu/h 11600/11800 11600/11800
Heating Capacity Btu/h / 10400/10600
Cooling Power Input W 1000/1015 1000/1015
Heating Power Input W / 895/910
Electric Heating Power Input W 4089/5000 4089/5000
Cooling Power Current A 5.1/4.9 5.1/4.9
Heating Power Current A / 4.7/4.2
Rated Input W 1306 1306
Rated Current A 7.10 7.10
EER (Btu/h)/W 11.6/11.6 11.6/11.6
COP W/W / 3.4/3.4
Air Flow Volume(H/M/L) CFM 341/306/- 341/306/-
Dehumidifying Volume
Pint/h 2.747
2.747
Application Area yd
2
16-24 16-24
Permissible Excessive Operating Pressure for the
Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure for the
Suction Side
MPa 2.5 2.5
Maximum Allowable Pressure MPa 4.3 4.3
Throttling Method Capillary Capillary
Defrosting Method / /
Climate Type T1 T1
Isolation I I
Moisture Protection IP24 IP24
Dimension (WXHXD) inch 42X16X21 1/2 42X16X21 1/2
Dimension of Carton Box (LXWXH) inch 45X25 5/16X17 7/8 45X25 5/16X17 7/8
Dimension of Package (LXWXH) inch 45X25 3/8X18 1/2 45X25 3/8X18 1/2
Net Weight lb 54.0 55.0
Gross Weight lb 63.0 64.0
Refrigerant / R410A R410A
Refrigerant Charge oz 35.27 35.27
Indoor Side
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ4 55/72X27 35/44 Φ4 55/72X27 35/44
Cooling Speed r/min 1130/970 1130/970
Heating Speed r/min 1130/970 1130/970
Fan Motor Power Output W 23 23
Fan Motor RLA A 0.20 0.20
Fan Motor Capacitor μF 1 1
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter inch Φ8/29 Φ8/29
Evaporator Coil Length (LXDXW) inch 27 13/25X9 19/36X1 1/2 27 13/25X9 19/36X1 1/2
Swing Motor Model / /
Swing Motor Power Output W / /
Fuse Current A 3.15 3.15
Set Temperature Range 61-86 61-86
Sound Pressure Level (H/M/L) dB (A) 53/-/50 53/-/50
Sound Power Level (H/M/L) dB (A) 63/-/60 63/-/60
