Service Manual
Installation and Maintenance
66
11. Removal Procedure
Caution: pull out the power,discharge the
refrigerant completely before removal.
StepsProcedure
1.Remove panel
panel case
clasp
filter
Hold the panel and pat both sides of
panel to separate the panels and then
remove the front panel.
Hold the front part of filter by hand, lift
up the filter and then remove the filter.
b
a
Note: Take heat pump+electric heating unit as example for the disassemly; cooling only+electric heating is a little different.
To Next Page
