Service Manual
Installation and Maintenance
65
Above data is subject to change without notice.
47 Fan Motor 1501180214 1501180214 1
48 Clapboard 0123115801 0123115801 1
49 Compressor and Fittings 00101377 00101378 1
50 Compressor Gasket 76710287 76710216 3
51 Outer Support Sub-assy(Right) 01701039 01701039 1
52 Cable Cross Plate 26111215 26111215 1
53 Filter Sub-Assy 11121607 11121607 1
54 Air Inlet Door 01441018P 01441018P 1
55 Inhalation Tube 03500600167 03500600158 1
56 Discharge Tube 1 03500800162 03500800155 1
57 Capillary Sub-assy 03000600104 03000600133 1
58 Drainage Valve 07101001 07101001 1
59 Chassis Sub-assy 01201241P 0120124108P 1
60 Foam (Water Tray) 12311048 12311048 1
61 Electric Box Assy 10000200006403 10000200006403 1
62 Junction lid / / /
63 Junction box / / /
64 Relay 4402033402 4402033402 1
65 Capacitor CBB61S 3301074710 3301074710 1
66 Transformer 43110269 43110269 1
67 Capacitor CBB65 33000081 33000081 1
68 Capacitor CBB61 3301074701 3301074701 1
69 Terminal Board 42011103 42011103 2
70 Radiator 49010252 49010252 1
71 Fuse 46010022 46010022 1
72 Wiring Terminal 42010037 42010037 1
73 Wiring Terminal 42010039S 42010039S 1
74 Pwer cord (LCDI) / / /
To Next Page
