Service Manual
Installation and Maintenance
63
Above data is subject to change without notice.
47 Fan Motor 1501180210 1501180212 1
48 Clapboard 0123115801 0123115801 1
49 Compressor and Fittings 00101375 00101376 1
50 Compressor Gasket 76710287 76710287 3
51 Outer Support Sub-assy(Right) 01701039 01701039 1
52 Cable Cross Plate 26111215 26111215 1
53 Filter Sub-Assy 11121607 11121607 1
54 Air Inlet Door 01441018P 01441018P 1
55 Inhalation Tube 03631666 03631665 1
56 Discharge Tube 1 03511010 03511012 1
57 Capillary Sub-assy 03000600111 03000600080 1
58 Drainage Valve 07101001 07101001 1
59 Chassis Sub-assy 01201241P 01201241P 1
60 Foam (Water Tray) 12311048 12311048 1
61 Electric Box Assy 100002000064 10000200006401 1
62 Junction lid / / /
63 Junction box / / /
64 Relay 4402033402 4402033402 1
65 Capacitor CBB61S 3301074701 3301074701 1
66 Transformer 43110269 43110269 1
67 Capacitor CBB65 3300008111 33010044 1
68 Capacitor CBB61 3301074716 3301074701 1
69 Terminal Board 42011103 42011103 2
70 Radiator 49010252 49010252 1
71 Fuse 46010022 46010022 1
72 Wiring Terminal 42010037 42010037 1
73 Wiring Terminal 42010039S 42010039S 1
74 Pwer cord (LCDI) / / /
