General Information
Installation Supplements
Refer to the appropriate Greenheck installation
supplements for special requirements:
• Concrete Floor with Steel Deck
• Drive Slip Breakaway Connection
• Field Installed Sleeve
• Fire Resistant Ventilated Duct Assembly
• Firestop Material
• Fusible Link Replacement
• Greenheck Test Switch
• Grille Installation
• Metal Stud in Shaftwall Partition
• Non-Concrete Horizontal Mount
• Open or Close Indicator (OCI)
• Quick Connect Breakaway Connection
• Resettable Link (RRL)
• Resettable Link with Blade Indicator
(RRL/OCI)
• Sealant Supplement
• Single 3-Sided Retaining Angle Supplement
• Sleeve Extension
• Smoke Detector - Various Types
• Temperature Limited Override (TOR)
• Tunnel Corridor
Installation supplements available at www.greenheck.
com.
The following items will aid in completing the damper
installation in a timely and effective manner.
1) Check the drawings for proper damper locations
within the building. Visually inspect the damper for
damage and verify that the Reusable Resettable Link
(RRL) is in place and has not activated if provided.
These electric links have a button for resetting.
Visually inspect the fusible link (if provided) to verify
its not missing or broken. Replace link as necessary.
2) Lift or handle damper using sleeve or frame. Do not
lift damper using blades or actuators.
3) Damper has label on outside of sleeve indicating
a ‘No Screw’ area. Do not install screws into this
area as screws may interfere with unexposed blade
linkage and prevent damper blades from opening
and/or closing.
4) Damper has label indicating position of damper
and sleeve assembly in the wall. Install accordingly
to comply with manufacturer’s appropriate UL
Classification file number.
5) Damper must be installed into duct or opening
square and free of twist or other misalignment. Out
of square, racked, twisted or misaligned installations
can cause excessive leakage and/or torque
requirements to exceed damper/actuator design.
6) Damper and actuator must be kept clean and
protected from dirt, dust and other foreign materials
prior to and after installation. Examples of such
foreign materials include but are not limited to:
a) Mortar dust
b) Drywall dust
c) Firesafing materials
d) Wall texture
e) Paint overspray
7) Damper should be sufficiently covered as to prevent
overspray if wall texturing or spray painting will be
performed within 5 feet of the damper. Excessive dirt
or foreign material deposits on the damper can cause
excessive leakage and/or torque requirements to
exceed damper/actuator design.
8) Caulking is not necessary, nor is it allowed, between
the damper sleeve and the wall or floor opening
(annular space). However, caulking may be applied to
the retaining angles.
9) ACCESS: Suitable access (such that RRLs and
actuators can be maintained, etc.) must be provided
for damper inspection and servicing. Where it is not
possible to achieve sufficient size access, it will be
necessary to install a removable section of duct.
(Refer to NFPA 90A).
10) The Code Authority Having Jurisdiction (AHJ) must
evaluate and provide approval of final installation
where variations to these instructions are necessary.
Electrical Guidelines
All wiring shall be done in accordance with the
National Electrical Code ANSI/NFPA-70 latest edition,
any local codes that may apply, and wiring diagrams
developed in compliance with the job or project
design and specifications.
Important!
Electrical input may be needed for this equipment.
This work should be performed by a qualified
electrician. Verify power before wiring actuator.
Greenheck is not responsible for any damage to, or
failure of the unit caused by incorrect field wiring. To
avoid causing death or serious bodily harm to building
occupants, follow all instructions carefully. Dampers
must close completely to preserve the integrity of the
fire smoke separation.
Electrical Guidelines
Pre-Installation Guidelines
“UL CLASSIFIED (see complete marking on
product)”
“UL CLASSIFIED to Canadian safety standards
(see complete marking on product)”
Standard 555 & 555S (Listing #R13317)
Multi-Blade Fire and Combination Fire Smoke Dampers2
