Greenheck DFD Series User Manual

3
Mixed Flow
REMOVING FROM STORAGE
As fans are removed from storage to be installed in their
final location, they should be protected and maintained
in a similar fashion, until the fan equipment goes into
operation.
Prior to fully assembling and installing the fan and
system components, inspect the fan assembly to make
sure it is in working order.
1. Check all fasteners, set screws, wheel, bearings,
drive, motor base and accessories for tightness.
2. Rotate the fan wheel by hand and assure no parts
are rubbing. Access to the wheel is obtained through
an access panel located on the side of the fan
housing.
3. Ensure proper wheel settings for radial gap and
alignment. See Unit Start-Up section.
Table of Contents
General Safety Information . . . . . . . . . . . . . . 1
Receiving, Unpacking, Handling . . . . . . . . . . . . 2
Storage - Indoor / Outdoor . . . . . . . . . . . . . . 2
Inspection and Maintenance During Storage . . . . . 2
Removing from Storage . . . . . . . . . . . . . . . . 3
Installation
Ducted Installations . . . . . . . . . . . . . . . . . 4
Non-Ducted Installations . . . . . . . . . . . . . . 4
Duct Connections . . . . . . . . . . . . . . . . . . 4
Mounting Configurations
Universal Mounting . . . . . . . . . . . . . . . . . 5
Mounting Rails (Optional) . . . . . . . . . . . . . 5-6
Ceiling Hung - Horizontal or Vertical . . . . . . . 6
Base Mount - Horizontal or Vertical . . . . . . . . 6
Installation for UL 762 Restaurant Exhaust
Installation Overview . . . . . . . . . . . . . . . 6-7
Cleaning, Maintenance, Repair . . . . . . . . . . . 7
Unit Start-Up . . . . . . . . . . . . . . . . . . . . . . 8
Radial Gap and Alignment . . . . . . . . . . . . . 8
Vibration . . . . . . . . . . . . . . . . . . . . . . . 8
Maintenance
V-Belt Drive . . . . . . . . . . . . . . . . . . . . . 9
V-Belt Replacement . . . . . . . . . . . . . . . . . 9
Motors . . . . . . . . . . . . . . . . . . . . . . . .10
Fan Bearing Replacement. . . . . . . . . . . . . .10
Fan Bearing Lubrication . . . . . . . . . . . . . . .10
Troubleshooting . . . . . . . . . . . . . . . . . . . .11
Our Commitment. . . . . . . . . . . . . . . Backcover
