Greenheck DFD Series User Manual

Centrifugal Inline Fans4
®
A
B
C
*E
D
*G
*F
1-1/2 in.
(38mm)
B
A
C
C
1-1/2 in.
(38mm)
1-1/2 in.
(38mm)
Optional cover varies with
motor size. Recommend
24 inch (610mm) clearance.
Belt Drive Fan Dimensions
Size A B C D *E *F *G Damper Weight^
70, 80, 90
17
1
⁄8
(435)
21
(533)
17
1
⁄8
(435)
11
7
⁄8
(302)
17
3
⁄4
(451)
13
(330)
13
1
⁄4
(337)
12
(305)
106
(48)
100
17
1
⁄8
(435)
21
(533)
17
1
⁄8
(435)
13
7
⁄8
(352)
17
3
⁄4
(451)
13
(330)
13
1
⁄4
(337)
14
(356)
107
(49)
120
19
1
⁄8
(486)
21
(533)
19
1
⁄8
(486)
15
7
⁄8
(403)
20
(508)
17
(432)
13
1
⁄4
(337)
16
(406)
124
(56)
130 (HP)
21
1
⁄8
(537)
21
(533)
21
1
⁄8
(537)
17
7
⁄8
(454)
20
(508)
17
(432)
13
1
⁄4
(337)
18
(457)
131
(59)
140 (HP)
23
1
⁄8
(587)
22
(559)
23
1
⁄8
(587)
19
7
⁄8
(505)
20
(508)
17
(432)
13
1
⁄4
(337)
20
(508)
146
(66)
160 (HP)
26
1
⁄8
(664)
26
(660)
26
1
⁄8
(664)
22
7
⁄8
(581)
20
(508)
17
(432)
13
1
⁄4
(337)
23
(584)
188
(85)
180 (HP)
27
1
⁄8
(689)
28
(711)
27
1
⁄8
(689)
23
7
⁄8
(606)
20
(508)
17
(432)
13
1
⁄4
(337)
24
(610)
195
(88)
200 (HP)
31
1
⁄8
(791)
32
(813)
31
1
⁄8
(791)
27
7
⁄8
(708)
30
(762)
20
(508)
16
(406)
28
(711)
246
(111)
240 (HP)
38
1
⁄8
(968)
34
(864)
38
1
⁄8
(968)
34
7
⁄8
(886)
30
(762)
20
(508)
16
(406)
35
(889)
350
(159)
300 (HP)
46
(1168)
38
(965)
46
(1168)
41
7
⁄8
(1064)
34
(864)
22
(559)
18
(457)
42
(1067)
537
(244)
360 (HP)
52
(1321)
42
(1067)
52
(1321)
47
7
⁄8
(1216)
34
(864)
22
(559)
18
(457)
48
(1219)
686
(311)
420
58
(1473)
50
(1270)
58
(1473)
53
7
⁄8
(1368)
34
(864)
22
(559)
18
(457)
54
(1372)
789
(358)
All dimensions in inches (millimeters) and weight is shown in pounds (kilograms).
*Motor cover is optional. Size may be greater depending on motor.
^Weight shown is standard galvanized construction and largest cataloged open drip proof motor.
Belt Drive Filter Option Dimensions
Size A B C Weight^ Filter Size Filter Quantity
70, 80, 90 53
7
⁄8 (1368) 17
1
⁄8 (435) 11
7
⁄8 (302) 168 (76) 16 x 20 (406 x 508) 2
100 53
7
⁄8 (1368) 17
1
⁄8 (435) 13
7
⁄8 (352) 169 (77) 16 x 20 (406 x 508) 2
120 58
3
⁄4 (1492) 19
1
⁄8 (486) 15
7
⁄8 (403) 194 (88) 16 x 25 (406 x 635) 2
130 (HP) 53
1
⁄4 (1353) 21
1
⁄8 (537) 17
7
⁄8 (454) 197 (89) 20 x 20 (508 x 508) 2
140 (HP) 59 (1500) 23
1
⁄8 (537) 19
7
⁄8 (505) 231 (105) 20 x 25 (508 x 635) 2
160 (HP) 58
3
⁄4 (1492) 26
1
⁄8 (664) 22
7
⁄8 (581) 285 (129) 20 x 20 (508 x 508) 4
180 (HP) 60
3
⁄4 (1543) 27
1
⁄8 (689) 23
7
⁄8 (606) 293 (133) 20 x 25 (508 x 635) 4
200 (HP) 69
3
⁄8 (1762) 31
1
⁄8 (791) 27
7
⁄8 (708) 361 (164)
12 x 25 (305 x 635) 3
16 x 25 (406 x 635) 3
240 (HP) 71
1
⁄2 (1816) 38
1
⁄8 (968) 34
7
⁄8 (886) 496 (225)
20 x 25 (508 x 635) 4
16 x 25 (406 x 635) 4
300 (HP) 72
1
⁄8 (1832) 46 (1168) 41
7
⁄8 (1064) 759 (344) 20 x 25 (508 x 635) 8
360 (HP) 79
1
⁄4 (2013) 52 (1321) 47
7
⁄8 (1216) 957 (434)
16 x 25 (406 x 635) 10
20 x 25
(508 x 635) 5
420 93
1
⁄8 (2365) 58 (1473) 53
7
⁄8 (1368) 1185 (538)
16 x 25 (406 x 635) 5
20 x 25 (508 x 635) 10
All dimensions in inches (millimeters) and weight is shown in pounds (kilograms).
^Weight shown is standard galvanized construction and largest cataloged open drip proof motor.
Note: 24 inch side clearance is recommended for accessing and removing filters.
Figure 3: Belt Drive
Fan Dimensions
Figure 4: Belt Drive
Filter Option Dimensions
